Current transformers 6(10)-35 kV

Current transformers series LZZB (production: HEAG) used in power plants in the distribution of high voltage circuits relaying, metering and billing of electricity.

The principle of operation is based on an electromagnetic transformer converting the measured current flowing through the primary winding, a current having a substantially smaller value proportional acceptable standard for measuring instrumentation.

Instruments series LZZB - single phase cast resin transformers reference type, which is made of epoxy resin (for indoor use), and with a shell made ​​of silicone rubber (for outdoor use).

Modifications for indoor installation (LZZBJ9-12, LZZBJ12-12, LZZB (J) 9-35, LZZB (J) 7-35) and outdoor (LZZBJ71-12W, LZZBW8-35) different nominal (most effective) voltage design mounting at the installation location, the number of windings, dimensions and weight.

Current transformers 6(10) kV

Current transformer LZZBJ9-12

Transformer with sealed cast insulation of support type. Used for transmission of metering signal of current to power metering devices, including commercial metering, relay protection and automation in power grid of 10kV 50Hz rated voltage.
Produced in accordance with standards GB1208-2006, IEC60044-1, ГОСТ 7746-2001.
CT has a terminal box with transparent cover for connection of secondary load with possibility of sealing.

Current transformer LZZBJ12-12

Transformer with sealed cast insulation of support type. Used for transmission of metering signal of current to power metering devices, including commercial metering, relay protection and automation in power grid of 10kV 50Hz rated voltage.
CT is produced and tested accordance with standards GB1208-2006, IEC60044-1, ГОСТ 7746-2001.
CT has a terminal box with transparent cover for connection of secondary load with possibility of sealing.

Current transformer LZZBJ71-12W

Трансформатор тока наружной установки с корпусной изоляцией опорного типа из литьевой смолы, герметичный. Используются для передачи сигнала измерения электрического тока к устройствам измерения и учета электрической энергии, включая системы коммерческого учета, релейной защиты и автоматики в электрических сетях с номинальным напряжением до 12 кВ. Изготовлен и испытан в соответствии со стандартом GB 1208-2006, IEC60044-1, ГОСТ 7746-2001.

Current transformers 35 kV

Current transformer LZZB7-35

LZZB7-35 (LZZB7-35W2 and LZZB7-35A) — support type current transformers in  cast resin insulation, sealed. CTs are used for transmission of metering signal of current to devices of metering of energy including commercial metering, relay protection in 35kV grid.
CTs compy with the following standards: GB1208-2006, IEC60044-1, ГОСТ 7746-2001.

Current transformer LZZBW8-35

LZZBW8-35 — current transformer of support type in cast resin sealed insulation. It is used for transmission of metering signal to to metering devices including commercial metering, relay protection and automation in 35kV grid.  CTs comply with requirements of GB1208-2006, IEC60044-1, ГОСТ 7746-2001.

Current transformer LZZBJ9-35

Трансформатор тока опорного типа в изоляции из литьевых смол, герметичный, для внутренней установки. Используется для передачи сигнала тока в системах измерения, релейной защиты, автоматики и управления электрических подстанций напряжением 35 кВ, 50Гц. Соответствует стандартам GB 1208-2006, IEC60044-1 и ГОСТ 7746-2001.

Zero sequence current transformers

Zero sequence current transformer LXK

Трансформаторы тока нулевой последовательности LXK используются в закрытых помещениях для сетей с изолированной нейтралью с номинальной частотой 50 Гц и номинальным напряжением от 10кВ.

Current transformers series LZZB (HEAG) entered in the National Register of SR RB.

Get advice, order or buy the current transformer you can have our sales managers.
